Flex Lighting — Curved Linear

Ref: Onda-NS149

Onda-NS149
Dual-Bend Flex

18 W/m · Dual-Bend · Multi-Optic · IP67 · 24VDC

High-output dual-bend flexible silicone linear with five selectable beam angles from 15° to 60°. 1860 lm/m at 102 lm/W efficacy. Six CCT options and full CE, UL, TUV-CE certification. Maximum run 5 m — designed for precision cove, reveal, and architectural accent applications.

Dual-Bend Multi-Optic IP67 CRI ≥90 DALI · DMX CE · UL · TUV

Spec Sheet ↓

Technical Data

Full Specification

Dimension

H15 × W20 mm

Max run 5,000mm

Wattage

18 W/m

Lumen Output

1860 lm/m

@ 3000K

Efficacy

102 lm/W

@ 3000K

Voltage

24V DC

CCT

2700K / 3000K / 3500K / 4000K

5000K / 6000K

CRI

Ra ≥90

3-Step MacAdam Ellipse

Beam Angle

15° / 25° / 30° / 45° / 60°

Selectable optic

Bend Type

Dual-Bend

Both axes (top & side)

IP Rating

IP67

LED / Chip

24 LED/m

3535 (15°) · 3030 (25°–60°)

Lifetime

50,000 hours

@ 65°C

Operating Temp

−20 to 45°C

Tc max < 65°C

Dimming / Control

0-10V · 1-10V · DMX · DALI

Certification

CE · UL · TUV-CE

Warranty

5 Years

Mounting

Clips / Tape / Bracket

Aluminum channel

PCB Increment

250 mm

Technical Files

Downloads

Photometric Data

View Spec Sheet PDF ↓
